Description
The General Purpose Anchor is a simply designed anchor for use in recessed or protruding precast concrete product applications.
General Purpose Anchor
General Purpose Anchors
General Purpose Anchors
| Part number | Height (in.) | Width | Wire diameter in | Foot diameter | Ult. Mech. Load | Item wt ea | Box/Skid | Box/Bag/Drum | hf:att:pa_height | hf:att:pa_ult-mech-load |
|---|---|---|---|---|---|---|---|---|---|---|
| PLGP146G | 6 | 2-5/8 | 1/4 | 1/2 | 6400 | .17 lbs | 100/10000 | 6 | 6400 | |
| PLGP516612G | 6-1/2 | 2-5/8 | 5/16 | 1/2 | 12800 | .34 lbs | 100/6500 | 6-1-2 | 12800 | |
| PLGP387G | 7 | 2-3/4 | 3/8 | 1 | 18760 | .55 lbs | 100/3500 | 7 | 18760 | |
| PLGP71611G | 11 | 3-1/2 | 7/16 | 1 | 30000 | 1.23 lbs | 25/2200 | 11 | 30000 | |
| PLGP7169G | 9 | 3-1/2 | 7/16 | 1 | 30000 | 1.06 lbs | 50/2500 | 9 | 30000 | |
| PLGP581612G | 16-1/2 | 12 | 5/8 | N/A | N/A | 3.42 lbs | 600/crate | 16-1-2 | n-a |
